Economic Horizontal Laminar Flow Cabinet
This page covers multiple model variants. Specs below are attributed per model where confirmed — confirm your exact configuration before ordering.
Some spec rows on this product could not be confidently matched to a specific model — marked below as unverified. Confirm these directly before relying on them.
Specifications
- Model
- LCB-H-LP1100E; LCB-H-LP1300E; LCB-H-LP1500E; LCB-H-LP1800E
- HEPA Filter
- 1 pcs, Efficiency: > 99.995% at particle size of 0.3 μm
- External Size
- 3ft / 4ft / 5ft
- Sound Emission
- ≤65 dB(A)
- Airflow Velocity
- 0.2~0.5 m/s, speed adjustable
- Work Surface Height
- 750mm
Full specification sheet
- Model [LCB-H-LP1100E]: LCB-H-LP1100E
- Model [LCB-H-LP1300E]: LCB-H-LP1300E
- Model [LCB-H-LP1500E]: LCB-H-LP1500E
- Model [LCB-H-LP1800E]: LCB-H-LP1800E
- External Size (W×D×H)(mm) [LCB-H-LP1100E]: 1100×750×1750
- External Size (W×D×H)(mm) [LCB-H-LP1300E]: 1300×750×1750
- External Size (W×D×H)(mm) [LCB-H-LP1500E]: 1500×750×1750
- External Size (W×D×H)(mm) [LCB-H-LP1800E]: 1800×750×1750
- Internal Size (W×D×H)(mm) [LCB-H-LP1100E]: 1020×510×620
- Internal Size (W×D×H)(mm) [LCB-H-LP1300E]: 1220×510×620
- Internal Size (W×D×H)(mm) [LCB-H-LP1500E]: 1420×510×620
- Internal Size (W×D×H)(mm) [LCB-H-LP1800E]: 1720×510×620
- Work Surface Height: 750mm
- Control System: Microprocessor controller with LCD display, display the operating status of each function
- Airflow System Airflow Velocity: 0.2~0.5m/s, speed adjustable
- Air filtration System Pre-Filter: 1pcs, polyester fiber, washable
- HEPA Filter: 1 pcs, Efficiency: > 99.995% at particle size of 0.3μm
- Cleanliness Grade: ISO Class 5 (formerly Class 100)
- Cabinet Construction Main Body: Electro-galvanized steel with antimicrobial powder coating
- Work Surface: 304 Stainless steel
- Side Window: 5 mm UV resistant tempered glass
- Electrical System [UNVERIFIED — 5 values, 4 models, check manually]: UV Lamp | 20W×1 | 30W×1 | 30W×1 | 18W×2
- Electrical System: With timing function, Interlock with LED lamp, blower, Socket. Emission of 253.7 nanometers for best sterilization effect.
- LED Lamp [LCB-H-LP1100E]: 6.5W×1
- LED Lamp [LCB-H-LP1300E]: 9.6W×1
- LED Lamp [LCB-H-LP1500E]: 9.6W×1
- LED Lamp [LCB-H-LP1800E]: 6.5W×2
- Consumption [LCB-H-LP1100E]: 160W
- Consumption [LCB-H-LP1300E]: 170W
- Consumption [LCB-H-LP1500E]: 300W
- Consumption [LCB-H-LP1800E]: 310W
- Consumption: Not include socket loading power consumption
- Power Supply: AC220V±10%, 50/60Hz; 110V±10%, 60Hz
- Illumination: ≥900 Lux
- Sound Emission: ≤65dB(A)
- Standard Accessory: 1. Base Stand; 2. LED Lamp; 3. UV lamp; 4. Waterproof Socket × 2; 5. Footmaster Caster
- Optional Accessory: 1. Air Velocity Sensor; 2. IV Bar with Hooks
- Net Weight (kg) [LCB-H-LP1100E]: 150
- Net Weight (kg) [LCB-H-LP1300E]: 170
- Net Weight (kg) [LCB-H-LP1500E]: 200
- Net Weight (kg) [LCB-H-LP1800E]: 225
- Gross Weight (kg) [LCB-H-LP1100E]: 210
- Gross Weight (kg) [LCB-H-LP1300E]: 230
- Gross Weight (kg) [LCB-H-LP1500E]: 260
- Gross Weight (kg) [LCB-H-LP1800E]: 290
- Shipping Size (W×D×H)(mm) [LCB-H-LP1100E]: 1240×930×1255
- Shipping Size (W×D×H)(mm) [LCB-H-LP1300E]: 1440×930×1255
- Shipping Size (W×D×H)(mm) [LCB-H-LP1500E]: 1640×930×1255
- Shipping Size (W×D×H)(mm) [LCB-H-LP1800E]: 1940×930×1255
- Shipping Volume (m³) [LCB-H-LP1100E]: 1.45
- Shipping Volume (m³) [LCB-H-LP1300E]: 1.7
- Shipping Volume (m³) [LCB-H-LP1500E]: 1.9
- Shipping Volume (m³) [LCB-H-LP1800E]: 2.3
